CRUCES CON REDUCCIÓN A 90º

CRUCES REDUCCION 90 AIR GALVA AIRTUB HELICOIDAL GALVANIZADOS

CRUCES CON REDUCCIÓN A 90º

-Descripción:
Cruces con Reducción a 90º construidas a partir de 3 piezas  ( tubo principal  e injertos a 90º perpendiculares entre ellos a 180º) El diametro de los injertos siempre sera inferior al tubo principal.

-Material:
Acero galvanizado con recubrimiento de zinc Z-200/ Z-275 de espesores 0.5,0.6,0.8 y 1 mm según el diámetro

-Diámetros Disponibles:
Desde Ø 80 hasta Ø 1600

-Tipo de unión:
Enchufable (Accesorios Macho y Tubos Hembra en ambas bocas ) Union mediante Tornillos autotaladrantes o remaches.

-Opciones:
Se puedan fabricar cruces con diferentes grados de inclinación en el injerto, variar el angulo entre injertos, diámetros a medida y modificar longitudes tanto en el tubo principal como en los injertos. Posibilidad de acabado M/H ,unión con Brida tipo “Metu”, brida plana (2/3 mm), tapa final e incluso malla electrosoldada.

Categorías:

A Continuación les indicamos los PVP. Si lo desea puede descargarse la pagina en pdf.

Ficha Técnica Codo 30º

Ficha Técnica Cruces con Reducción a 90º

Catálogo PDF Airtub

Tarifa Cruces con Reducción a 90º



Ø801001251501601752002252502753003153504004505005506006306507007508008509009501000105011100115012001250130014001500
10013,2213,62
12513,2213,62
15014,4514,8917,28
16014,7615,2217,5418,77
17515,1015,5517,8120,2621,38
20015,5816,0618,6621,1822,5123,82
22518,5019,0821,3823,7025,7327,7430,53
25019,4920,0922,6924,0026,0428,0632,5936,59
27519,7820,3822,8125,1427,6030,0734,1037,6439,25
30020,8021,4424,4130,1830,8931,5835,1238,6540,5144,59
31521,7222,3927,5531,2732,3433,4036,7340,1642,5846,2247,23
35022,2622,9629,0631,5833,5635,5439,2542,1346,2249,6953,2758,32
40024,2825,0329,7633,5035,6937,8541,3845,2249,3452,2658,3260,3465,90
45025,7526,5431,5835,1237,3639,5842,5846,7350,6655,7260,1362,8670,1483,54
50027,2428,0934,3038,1540,1642,1846,6349,2553,2758,7462,7767,4273,8686,0393,04
55030,3431,2736,5540,3743,6646,9451,6756,8161,8570,8477,5289,7194,2499,79101,42112,01
60043,1947,5351,8654,2359,2866,1974,8884,5591,6397,49100,42106,27112,51120,89
63049,9052,2755,1362,8670,5580,2387,7993,8698,59101,22108,08117,59128,96138,30
65052,6856,0266,4174,8885,5891,0296,0799,71102,02109,90122,66137,04147,62152,80
70069,8476,5189,1191,8297,08100,21109,60114,22126,95139,62151,21157,96164,69
75072,4685,9891,8296,98100,09109,49114,22126,36130,98140,68160,97170,20179,42197,69
80090,8697,69105,14112,01120,50127,37132,19140,88151,15167,33175,74184,16201,62217,16
850100,80110,81120,29127,25132,19141,07150,86167,33183,96192,48201,01217,16230,48237,44
900112,81127,37133,00141,07150,86165,70182,86200,00207,10214,19224,84232,34247,69263,38
950115,75129,58141,07150,86165,82187,50198,85214,03219,43224,84232,30247,45253,30272,21289,10
1000139,87150,86169,85187,50197,99214,03223,82228,06232,30247,84254,09267,42281,64292,38306,28
1050203,03215,59224,33228,31232,30247,84254,09269,84287,23298,82325,38346,30
1100208,08217,16224,84228,58232,30247,84254,09272,26292,84305,27344,50367,21385,69
1150220,09228,62234,35240,07255,05274,28288,91318,58334,66365,36388,45404,18417,14
1200223,01232,40240,12247,84262,27294,48305,57344,32364,04386,23409,69419,89430,10443,76
1250247,84258,43269,04284,47346,24344,93364,04386,20407,69432,71442,39452,09457,43462,77
1300271,00283,56304,56348,76367,13386,20411,47437,46451,82461,50471,16485,69500,21519,46
1400348,96364,31388,42408,89437,86449,86470,57482,32494,08505,51516,94541,60563,92
1500392,34410,20441,19449,27467,54490,63506,58522,52532,31542,10560,36582,56617,39
1600418,50437,54470,60479,22498,71523,34540,35557,35567,79578,24597,72621,41658,55695,96
